Some developement v2

At first some Soldering:

Then heavy testing:

Differential signals are a perfect opportunity to max out the Rigol. Ch 1: TX Ch 2: RX Ch 3: RS484- A Ch 4: RS485+ B Math: A-B Decode1: TX+RX

Luckily my initial Problems tuned out to be soft ones.

For now my new Version is much more usable.

Unmanned harpoon

That's what Rosetta will fire at poor ol' Churyumov–Gerasimenko in November, any other Duck might be scared. Remember all the technology has been launched Years before the first Smartphone. Mankind has come quite a long way.

Rosetta's harpoon

On Max-Planck-Institut für extraterrestrische Physik is a very detailed (german) Presentation.

Further Informations from the Manufacturer: Faulhaber

See it in action : Scientists Test Harpoon Used in Rosetta Probe
